Nikon D5200 Digital SLR Camera Features & Technical Specs


DISCOVER NEW PERSPECTIVES

Newly developed Nikon DX-format CMOS sensor with 24.1 effective megapixels [NEW]
The high pixel count of 24.1 effective megapixels delivers high-definition images with fine details of the subject enabling expression with sharpness and depth. The image maintains high resolution even if it is trimmed and printed in large size after shooting.

High-density 39-point AF system features superior subject-tracking and subject-identification performance in combination with Scene Recognition System
The D5200 employs a Multi-CAM 4800DX autofocus sensor module. 39 focus points track even a fast-moving subject precisely. Furthermore, performance of auto-area AF and 3D-tracking is improved in combination with the Scene Recognition System that utilizes a 2016-pixel RGB sensor.

A choice of three body colors and a vari-angle LCD monitor that offers flexible shooting
The D5200 is available in black, red or bronze body colors. And it incorporates a vari-angle LCD monitor that enables you to set the angle you want. Compared with viewfinder shooting, you can shoot in a variety of angles from high or low with a stable posture. This expands flexibility of composition and further enhances your creativity.


Type
Single-lens reflex digital camera
Lens mount
Nikon F mount (with AF contacts)
Effective angle of view
Nikon DX format; focal length equivalent to approx. 1.5x that of lenses with FX-format angle of view
Effective pixels
24.1 million
Image sensor
23.5 x 15.6 mm CMOS sensor
Dust-reduction system
Image sensor cleaning, Airflow Control System, Image Dust Off reference data (optional Capture NX 2 software required)
File format
NEF (RAW): 14 bit, compressed
JPEG: JPEG-Baseline compliant with fine (approx. 1:4), normal (approx. 1:8) or basic (approx. 1:16) compression
NEF (RAW)+JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats
Media
SD (Secure Digital) and UHS-I compliant SDHC and SDXC memory cards
Viewfinder Coverage
Approx. 95% horizontal and 95% vertical
Shutter Type
Electronically controlled vertical-travel focal-plane shutter
Shutter Speed
1/4000 to 30 s in steps of 1/3 or 1/2 EV, bulb, time (requires optional ML-L3 Remote Control)
Flash sync speed
X=1/200 s; synchronizes with shutter at 1/200 s or slower
Maximum Burst Rate
5fps
Metering mode
TTL exposure metering using 2016-pixel RGB sensor
Exposure bracketing
3 shots in steps of 1/3 or 1/2 EV
ISO sensitivity
(Recommended Exposure Index)
ISO 100 to 6400 in steps of 1/3 EV; can also be set to approx. 0.3, 0.7, 1 or 2 EV (ISO 25600 equivalent) above ISO 6400; auto ISO sensitivity control available
Autofocus
Nikon Multi-CAM 4800DX autofocus sensor module with TTL phase detection, 39 focus points (including 9 cross-type sensors), and AF-assist illuminator (range approx. 0.5 to 3 m/1 ft 8 in. to 9 ft 10 in.)
Detection range
-1 to +19 EV (ISO 100, 20°C/68°F)
AF-area modes
Single-point AF, 9-, 21- or 39-point dynamic-area AF, 3D-tracking, auto-area AF
Nikon Creative Lighting
System (CLS)
Advanced Wireless Lighting supported with SB-910, SB-900, SB-800 or SB-700 as a master flash or SU-800 as commander; Flash Color Information Communication supported with all CLS-compatible flash units
Movie
1920 x 1080, 60i (59.94 fields/s)/50i (50 fields/s)*, ★ high/normal
1920 x 1080, 30p (progressive)/25p/24p, ★ high/normal
1280 x 720, 60p/50p, ★ high/normal
640 x 424, 30p/25p, ★ high/normal
File format
MOV
Video compression
H.264/MPEG-4 Advanced Video Coding
Monitor
7.5-cm (3-in.), approx. 921k-dot (VGA), vari-angle TFT monitor with 170° viewing angle, approx. 100% frame coverage, and brightness adjustment
Battery
One EN-EL14 Rechargeable Li-ion Battery
AC adapter
EH-5b AC Adapter; requires EP-5A Power Connector (available separately)
Dimensions
(W x H x D)
Approx. 129 x 98 x 78 mm/5.1 x 3.9 x 3.1 in.
Weight
Approx. 555 g/1 lb 3.6 oz with battery and memory card but without body cap; approx. 505 g/1 lb 1.8 oz (camera body only)
Supplied accessories
(may differ by country or area)
EN-EL14 Rechargeable Li-ion Battery, MH-24 Battery Charger, DK-5 Eyepiece Cap, DK-20 Rubber Eyecup, UC-E17 USB Cable, EG-CP16 Audio Video Cable, AN-DC3 Camera Strap, BF-1B Body Cap, BS-1 Accessory Shoe Cover, ViewNX 2 CD-ROM





-->
